Model

XS-9504N

XS-9508N

System

Operating System

Embedded LINUX

System Resources

multi-channel real-time recording and playback, multi-channel net operation for several persons, USB backup

Operation Interface

16-bit true color graphical menu interface and mouse support

Menu display

1/4 screen

1/4/8

Language

Chinese/English, French, German, Italian, Polish, Portuguese, Russian, Spanish, Turkish, Arab

Video

Video Standards

PAL(625 line,50 f/s);NTSC(525 line,60 f/s)

Surveillance quality

PAL,D1(704×576);NTSC,D1(704×480)

Playback quality

PAL,CIF(352×288)/D1(704×576);;NTSC,CIF(352×240)/D1(704×480)

Frame Rate

PAL:100fps; NTSC:120fps

PAL:200fps ; NTSC:240fps

Motion Detection

Zones:396(22*18)detection zones, many levels of Sensitivity setting

Audio

Audio Compression

G711A

Bidirectional Talk

Support

Recording Mode

Manual> >Dynamic Detection>Timing

Record &

Playback

Playback

One channel or multi-channel playback

Search Mode

Time/Date ,Motion Detection & exact search(accurate to second)

Space Occupation

Audio:28.8MB/H   Video:25~450MB/H

Storage &

Backup

Video storage

Hard disk, , and net

Backup Mode

Network, mobile Hard disk and USB

Interface

Video Input

4channel, BNC, 1.0Vp-p,75Ω

8channel,BNC, 1.0Vp-p,75Ω

Video Output

1 channel, BNC, 1.0Vp-p,75Ω and 1 VGA output

Audio Input

4 channel RCA

8channel RCA

Audio Output

1 channel ,RCA, 200-3000mV,5KΩ

Net Interface

RJ-45 (10M/100M)

PTZ Control

1 RS485

USB Interface

2*USB

Hard Disk

1 SATA, 2000G*1(OR 2PCS optional)

Power Supply

12V/4A

Environmental

Power Consumption

<10W(without hard disk)

Working Temperature

0℃-+55℃

Working Humidity

10%-90%

Atmosphere Pressure

86kpa-106kpa

Dimension

mm

Weight

2.5 kg
